1. The Evolution of Traffic Management Systems
-
Comprehensive Coverage: 360° or 180° views to monitor intersections, highways, and public spaces.
-
Real-Time Analytics: Detect accidents, congestion, and violations (e.g., speeding, illegal parking).
-
Data-Driven Insights: Provide traffic flow metrics to optimize signal timing and urban planning.
2. Technical Breakthroughs in Dahua’s Panoramic Cameras
2.1 High-Resolution Imaging
-
4K/8K Ultra HD Resolution: Capture license plates, vehicle details, and pedestrian movements with pinpoint accuracy.
-
Wide Dynamic Range (WDR): Balances bright and dark areas in high-contrast environments (e.g., tunnels, sunrise/sunset).
2.2 AI-Powered Analytics
-
Behavioral Detection: Identify abnormal behaviors (e.g., sudden stops, wrong-way driving, jaywalking).
-
Vehicle Classification: Differentiate cars, buses, trucks, and motorcycles.
-
Queue Length Estimation: Calculate waiting times at intersections to adjust traffic signals.
2.3 Edge Computing
2.4 Rugged Design
-
IP67/IP68 Ratings: Withstand extreme weather (rain, snow, dust).
-
Anti-Glare Coating: Minimize reflections from headlights and sunlight.
3. Applications in Traffic Management
3.1 Smart Intersection Management
3.2 Highway Surveillance
-
Accident Detection: Alerts authorities within 30 seconds of a collision.
-
Congestion Management: Use AI to predict bottlenecks and suggest alternate routes.
3.3 Parking Optimization
-
Occupancy Detection: Guide drivers to available spots via dynamic signage.
-
Illegal Parking Enforcement: Issue fines automatically in no-stopping zones.
3.4 Bus Rapid Transit (BRT) Systems
3.5 Additional Applications
-
Toll Collection Systems: Dahua’s panoramic cameras are used in toll plazas to identify vehicles and process payments without stopping.
-
School Zone Monitoring: Cameras monitor areas around schools to enforce speed limits and ensure pedestrian safety during peak times.
DAHUA IPC-HDBW5842R-ASE 8MP IR Fixed-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5842R-ASE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30fps
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HF5842F-ZE 8MP Box WizMind Network Camera
IPC-HF5842F-ZE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.
> Supports P-Iris, the camera can control the iris more precisely for better image effect.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> 12 VDC power output, and max. current 165 mA, easy for installation.
> SMD 3.0.
DAHUA IPC-HFW5842T-SE 8MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5842T-SE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5842T-ASE 8MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5842T-ASE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDW5842T-ZE 8MP IR Vari-focal Eyeball WizMind Network Camera
IPC-HDW5842T-ZE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HDW5842TM-ASE 8MP IR Fixed-focal Eyeball WizMind Network Camera
IPC-HDW5842TM-ASE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HFW5842H-Z4HE 8MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5842H-Z4HE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
> Anti-corrosion model optional.
DAHUA IPC-HFW5842H-ZHE 8MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5842H-ZHE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
> Anti-corrosion model optional.
DAHUA IPC-HDBW5842H-Z4HE 8MP IR Vari-focal Dome WizMind Network Camera
IPC-HDBW5842H-Z4HE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
> Anti-corrosion model optional.
DAHUA IPC-HDBW5842H-ZHE 8MP IR Vari-focal Dome WizMind Network Camera
IPC-HDBW5842H-ZHE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
> Anti-corrosion model optional.
DAHUA IPC-HFW5842E-ZHE 8MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5842E-ZHE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
>Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
DAHUA IPC-HFW5842E-Z4E 8MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5842E-Z4E
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0
DAHUA IPC-HFW5842E-ZE 8MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5842E-ZE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5842E-ASE 8MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5842E-ASE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840×2160) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HDBW5842E-ZHE 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
DAHUA IPC-HDBW5842E-Z4E 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5842E-Z4E
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDBW5842E-ZE 8MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5842E-ZE
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8MP (3840×2160) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HF5541F-ZE 5MP Box WizMind Network Camera
IPC-HF5541F-ZE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.
> Supports P-iris, the camera can control the iris more precisely for better image effect.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> SMD 3.0.
DAHUA IPC-HDW5541T-ZE 5MP IR Vari-focal Eyeball WizMind Network Camera
IPC-HDW5541T-ZE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HFW5541E-ZHE 5MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5541E-ZHE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
DAHUA IPC-HFW5541E-Z5E 5MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5541E-Z5E
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5541E-ZE 5MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5541E-ZE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0
DAHUA IPC-HDBW5541E-ZHE 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5541E-ZHE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 24V AC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
DAHUA IPC-HDBW5541E-Z5E 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5541E-Z5E
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 24V AC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDBW5541E-ZE 5MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5541E-ZE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 24V AC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5541E-ASE 5MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5541E-ASE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5 MP (2960×1668) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HFW5541T-SE 5MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5541T-SE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5 MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5541T-ASE 5MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5541T-ASE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5 MP (2960×1668) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDBW5541R-ASE 5MP IR Fixed-focal Dome WizMind Network Camera
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5 MP (2960×1668) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDW5541TM-ASE 5MP IR Fixed-focal Eyeball WizMind Network Camera
IPC-HDW5541TM-ASE
> 5-MP 1/2.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 5 MP (2960 × 1668) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HF5442F-ZE 4MP Box WizMind Network Camera
IPC-HF5442F-ZE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.
> Supports P-Iris, the camera can control the iris more precisely for better image effect.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> 12 VDC power output, and max. current 165 mA, easy for installation.
> SMD 3.0.
DAHUA IPC-HFW5442T-ASE 4MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5442T-ASE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5442T-SE 4MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5442T-SE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDW5442T-ZE 4MP IR Vari-focal Eyeball WizMind Network Camera
IPC-HDW5442T-ZE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HDW5442TM-ASE 4MP IR Fixed-focal Eyeball WizMind Network Camera
IPC-HDW5442TM-ASE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30fps
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HDBW5442R-ASE 4MP IR Fixed-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5442R-ASE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30fps
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5442H-Z4HE 4MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5442H-Z4HE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
DAHUA IPC-HFW5442H-ZHE 4MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5442H-ZHE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
> Anti-corrosion model optional.
DAHUA IPC-HDBW5442H-Z4HE 4MP IR Vari-focal Dome WizMind Network Camera
IPC-HDBW5442H-Z4HE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
> Anti-corrosion model optional.
DAHUA IPC-HDBW5442H-ZHE 4MP IR Vari-focal Dome WizMind Network Camera
IPC-HDBW5442H-ZHE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; analog output; power output; supports max. 512 G Micro SD card, built-in dual Mic.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
> Anti-corrosion model optional.
DAHUA IPC-HFW5442E-ZHE 4MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5442E-ZHE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
DAHUA IPC-HFW5442E-Z4E 4MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5442E-Z4E
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5442E-ZE 4MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5442E-ZE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5442E-ASE 4MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5442E-ASE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688×1520) @25/30fps
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HDBW5442E-ZHE 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5442E-ZHE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> IP67 and IK10 protection, heater.
> SMD 3.0.
DAHUA IPC-HDBW5442E-Z4E 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5442E-Z4E
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDBW5442E-ZE 4MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5442E-ZE
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4MP (2688×1520) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/24 VAC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HF5241F-ZE 2MP Box WizMind Network Camera
IPC-HF5241F-ZE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30 fps.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 2 out; audio: 2 in, 1 out; 485; BNC; supports max. 512 GB Micro SD card, built-in MIC.
> Supports P-iris, the camera can control the iris more precisely for better image effect.
> 24 VAC/12 VDC/PoE power supply; ePoE.
> SMD 3.0.
DAHUA IPC-HDW5241T-ZE 2MP IR Vari-focal Eyeball WizMind Network Camera
IPC-HDW5241T-ZE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HFW5241E-Z12E 2MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5241E-Z12E
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 150 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK1
> SMD 3.0.
DAHUA IPC-HFW5241E-Z5E 2MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5241E-Z5E
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5241E-ZE 2MP IR Vari-focal Bullet WizMind Network Camera
IPC-HFW5241E-ZE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDBW5241E-Z5E 2MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5241E-Z5E
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 24V AC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDBW5241E-ZE 2MP IR Vari-focal Vandal-proof Dome WizMind Network Camera
IPC-HDBW5241E-ZE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 2 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 24V AC/12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5241E-ASE 2MP IR Fixed-focal Dome WizMind Network Camera
IPC-HFW5241E-ASE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HFW5241T-SE 2MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5241T-SE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, IVS, face detection, smart object detection, and people counting, etc.
> Supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HFW5241T-ASE 2MP IR Fixed-focal Bullet WizMind Network Camera
IPC-HFW5241T-ASE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDBW5241R-ASE 2MP IR Fixed-focal Dome WizMind Network Camera
IPC-HDBW5241R-ASE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 and IK10 protection.
> SMD 3.0.
DAHUA IPC-HDW5241TM-ASE 2MP IR Fixed-focal Eyeball WizMind Network Camera
IPC-HDW5241TM-ASE
> 2-MP 1/2.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 2MP (1920×1080) @25/30fps.
> Built-in IR LED, and the max. illumination distance is 50 m.
> ROI, SVC, SMART H.264+/H.265+, AI H.264/H.265, encoding after filter, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> With deep learning algorithm, it supports: video metadata, smart sound detection, IVS, face detection, smart object detection, and people counting, etc.
> Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 512 GB Micro SD card, built-in MIC.
> 12 VDC/PoE power supply; ePoE.
> IP67 protection.
> SMD 3.0.
DAHUA IPC-HDBW71242E1-Z-X 12MP IR Dome WizMind Network Camera
IPC-HDBW71242E1-Z-X
> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 12 MP (4000 × 3000)@25/30 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> Built-in dual MICs; 1-ch speaker; support two-way talk.
> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection, Anti-Corrosion coating (optional).
DAHUA IPC-HFW71242H-Z-X 12MP IR Bullet WizMind Network Camera
IPC-HFW71242H-Z-X
> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 12 MP (4000 × 3000)@25/30 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection, Anti-Corrosion coating (optional).
DAHUA IPC-HF71242F-Z-X 12MP Box WizMind Network Camera
IPC-HF71242F-Z-X
> 12-MP 1/1.7″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 12 MP (4000 × 3000)@25/30 fps.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
DAHUA IPC-HF7842F-Z-X 8MP BOX WizMind Network Camera
IPC-HF7842F-Z-X
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@50/60 fps.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
DAHUA IPC-HDBW7842E1-Z4-X 8MP IR Dome WizMind Network CAMERA
IPC-HDBW7842E1-Z4-X
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@50/60 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> ROI, flexible coding, applicable to various bandwidth and storage environments. · Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.
> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.
> Built-in dual MICs; 1-ch speaker; support two-way talk.
> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection, Anti-Corrosion coating (optional).
DAHUA IPC-HDBW7842E1-Z-X 8MP IR Dome WizMind Network CAMERA
IPC-HDBW7842E1-Z-X
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@50/60 fps
> Built-in IR LED, and the max. illumination distance is 40 m.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection:Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.
> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.
> Built-in dual MICs; 1-ch speaker; support two-way talk.
> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection, Anti-Corrosion coating (optional).
DAHUA IPC-HFW7842H-Z4-X 8MP IR Bullet WizMind Network Camera
IPC-HFW7842H-Z4-X
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@50/60 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection.
> Anti-Corrosion coating(optional).
DAHUA IPC-HFW7842H-Z-X 8MP IR Bullet WizMind Network Camera
IPC-HFW7842H-Z-X
> 8-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 8 MP (3840 × 2160)@50/60 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection.
> Anti-Corrosion coating(optional).
DAHUA IPC-HF7442F-Z-X 4MP BOX WizMind Network Camera
IPC-HF7442F-Z-X
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688 × 1520)@50/60 fps.
> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Alarm: 2 in, 2 out; audio: 2 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
DAHUA IPC-HDBW7442E1-Z4-X 4MP IR Dome WizMind Network Camera
IPC-HDBW7442E1-Z4-X
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688 × 1520)@50/60 fps.
> Built-in IR LED, and the max. illumination distance is 80 m.
> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.
> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.
> Built-in dual MICs; 1-ch speaker; support two-way talk.
> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection, Anti-Corrosion coating (optional).
DAHUA IPC-HDBW7442E1-Z-X 4MP IR Dome WizMind Network CAMERA
IPC-HDBW7442E1-Z-X
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688 × 1520)@50/60 fps.
> Built-in IR LED, and the max. illumination distance is 40 m.
> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Built-in Hi-Fi large-diameter speaker covers an auditory range of 20 meters.
> Sound Management: With its built-in dual MICs and Dahua noise reduction algorithms, the camera supports the sound management function, using it to collect vocals, adaptively reduce noise, and filter non-human voices.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.
> Built-in dual MICs; 1-ch speaker; support two-way talk.
> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection, Anti-Corrosion coating (optional).
DAHUA IPC-HFW7442H-Z4-X 4MP IR Bullet WizMind Network Camera
IPC-HFW7442H-Z4-X
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688 × 1520)@50/60 fps.
> Built-in IR LED, and the max. illumination distance is 120 m.
> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 512 G Micro SD card.
> 12 VDC/24VAC/PoE+ (802.3at)/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection.
> Anti-corrosion coating (optional).
DAHUA IPC-HFW7442H-Z-X 4MP IR Bullet WizMind Network Camera
IPC-HFW7442H-Z-X
> 4-MP 1/1.8″ CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688 × 1520)@50/60 fps.
> Built-in IR LED, and the max. illumination distance is 60 m.
> Time-Division Exposure technology ensures that when the device is taking multiple snapshots of more than one targets, the quality of the snapshots will not be affected. It can also be used to adjust the brightness, speed and more of targets, to produce high quality snapshots.
> ROI, flexible coding, applicable to various bandwidth and storage environments.
> Two intelligent functions can be enabled at the same time, such as face recognition+people counting, face detection+people counting and PPE Detection+IVS.
> With deep learning algorithm, it supports: face recognition, face detection, IVS, people counting, video metadata, PPE Detection, parking space management and ANPR, etc.
> Privacy Protection: Mosaics can be automatically placed over the face or body of a person to protect their privacy.
> Alarm: 3 in, 2 out; audio: 1 in, 1 out; RS-485, BNC; supports max. 512 G Micro SD card.
> 12 VDC/24 VAC/PoE+/ePoE power supply, 12 VDC power output, max. current 165 mA and peak current is 700 mA, easy for installation.
> IP67 and IK10 protection.
> Anti-Corrosion coating(optional).
4. Case Studies: Dahua’s Impact
4.1 Dubai’s Smart City Initiative
4.2 London’s Congestion Charge Zone
4.3 Singapore’s Expressways
4.4 Mongolia’s Ulaanbaatar Project
4.5 Recife Subway, Brazil
5. Competitive Analysis: Dahua vs. Competitors
| Feature | Dahua | Hikvision | Axis Communications |
|---|---|---|---|
| Resolution | 8K | 4K | 4K |
| Analytics | AI-driven traffic-specific algorithms | Generic AI | Open platform with third-party apps |
| Edge Computing | Built-in quad-core processor | Optional module | Cloud-dependent |
| Price (Per Unit) | $1,200–$1,800 | $1,000–$1,500 | $1,500–$2,200 |
6. Future Trends
6.1 5G Integration
6.2 Vehicle-to-Infrastructure (V2I) Communication
6.3 Predictive Analytics
About The Author
- IPC-A22E-A
- IPC-A22E-B
- IPC-A22E-G
- IPC-A22E-S2
- IPC-A26H
- IPC-A26H-V2
- IPC-A26HI
- IPC-A26L
- IPC-A42
- IPC-A42-B
- IPC-A42-D
- IPC-A46L
- IPC-A46L-D
- IPC-B46L
- IPC-B46L-White
- IPC-C22C
- IPC-C22E-A
- IPC-C22E-S2
- IPC-C26E-V2
- IPC-D22M
- IPC-D42
- IPC-D42M
- IPC-EB5541-AS
- IPC-EB5541-M-AS
- IPC-EB5541-M12-SA
- IPC-EB81242-PD
- IPC-EBW81230
- IPC-EBW81242-AS-IVC-S2
- IPC-EBW81242-AS-S2
- IPC-EBW8630
- IPC-EBW8842-AS
- IPC-EBW8842-AS-IVC
- IPC-EW5541-AS
- IPC-F22
- IPC-F22A
- IPC-F22F
- IPC-F22FE
- IPC-F26F
- IPC-F26FE
- IPC-F42-D
- IPC-F42F
- IPC-F42F-D
- IPC-F42FE
- IPC-F42FE-D
- IPC-F46F
- IPC-F46FE-D
- IPC-F88FI-V2
- IPC-G22
- IPC-G22M
- IPC-G42
- IPC-G42M
- IPC-HCBW8442
- IPC-HDBW1230DE-SW
- IPC-HDBW1230E-S5
- IPC-HDBW1230R-ZS-S5
- IPC-HDBW1430DE-SW
- IPC-HDBW1431E-S4
- IPC-HDBW1431R-ZS-S4
- IPC-HDBW1530E-S6
- IPC-HDBW1830E-S6
- IPC-HDBW2230E-S-S2
- IPC-HDBW2231E-S-S2
- IPC-HDBW2231F-AS-S2
- IPC-HDBW2231R-ZAS-S2
- IPC-HDBW2231R-ZS-S2
- IPC-HDBW2241E-S
- IPC-HDBW2241R-ZAS
- IPC-HDBW2241R-ZS
- IPC-HDBW2431E-S-S2
- IPC-HDBW2431F-AS-S2
- IPC-HDBW2431R-ZAS-S2
- IPC-HDBW2431R-ZS-S2
- IPC-HDBW2441E-S
- IPC-HDBW2441R-ZAS
- IPC-HDBW2441R-ZS
- IPC-HDBW2531E-S-S2
- IPC-HDBW2531R-ZAS-S2
- IPC-HDBW2531R-ZS-S2
- IPC-HDBW2541E-S
- IPC-HDBW2541R-ZAS
- IPC-HDBW2541R-ZS
- IPC-HDBW2831E-S-S2
- IPC-HDBW2831R-ZAS-S2
- IPC-HDBW2831R-ZS-S2
- IPC-HDBW2841E-S
- IPC-HDBW2841R-ZAS
- IPC-HDBW2841R-ZS
- IPC-HDBW3231F-M
- IPC-HDBW3231F-M12
- IPC-HDBW3241E-AS
- IPC-HDBW3241E-AS-S2
- IPC-HDBW3241E-S
- IPC-HDBW3241E-S-S2
- IPC-HDBW3241F-AS-M
- IPC-HDBW3241F-AS-S2-0210B
- IPC-HDBW3241R-ZAS
- IPC-HDBW3241R-ZAS-S2
- IPC-HDBW3241R-ZS
- IPC-HDBW3241R-ZS-S2
- IPC-HDBW3249E-AS-NI
- IPC-HDBW3441E-AS
- IPC-HDBW3441E-AS-S2
- IPC-HDBW3441E-S
- IPC-HDBW3441E-S-S2
- IPC-HDBW3441F-AS-M
- IPC-HDBW3441F-AS-S2-0210B
- IPC-HDBW3441F-AS-S2-0280B
- IPC-HDBW3441R-AS-P
- IPC-HDBW3441R-ZAS
- IPC-HDBW3441R-ZAS-S2
- IPC-HDBW3441R-ZS
- IPC-HDBW3441R-ZS-S2
- IPC-HDBW3449E-AS-NI
- IPC-HDBW3449R1-ZAS-PV
- IPC-HDBW3541E-AS
- IPC-HDBW3541E-AS-S2
- IPC-HDBW3541E-S
- IPC-HDBW3541E-S-S2
- IPC-HDBW3541F-AS-M
- IPC-HDBW3541F-AS-S2
- IPC-HDBW3541R-ZAS
- IPC-HDBW3541R-ZAS-S2
- IPC-HDBW3541R-ZS-S2
- IPC-HDBW3549R1-ZAS-PV
- IPC-HDBW3841E-AS
- IPC-HDBW3841E-AS-S2
- IPC-HDBW3841E-S
- IPC-HDBW3841E-S-S2
- IPC-HDBW3841R-ZAS
- IPC-HDBW3841R-ZAS-S2
- IPC-HDBW3841R-ZS
- IPC-HDBW3841R-ZS-S2
- IPC-HDBW3849R1-ZAS-PV
- IPC-HDBW4231E-AS-S4
- IPC-HDBW4231E-S-S4
- IPC-HDBW4231E-Z-S4
- IPC-HDBW4231F-E2-M12
- IPC-HDBW4431E-AS-S4
- IPC-HDBW4431E-S-S4
- IPC-HDBW4431E-Z-S4
- IPC-HDBW4431F-M
- IPC-HDBW4431F-M12
- IPC-HDBW4431F-M12-CER
- IPC-HDBW4441E-AS
- IPC-HDBW4831E-ASE
- IPC-HDBW5231E-ZE-HDMI
- IPC-HDBW5241E-Z5E
- IPC-HDBW5241E-Z5E-S3
- IPC-HDBW5241E-ZE
- IPC-HDBW5241E-ZE-S3
- IPC-HDBW5241E-ZHE
- IPC-HDBW5241F-M
- IPC-HDBW5241F-M-SA
- IPC-HDBW5241F-M12
- IPC-HDBW5241F-M12-SA
- IPC-HDBW5241R-ASE
- IPC-HDBW5241R-ASE-S3
- IPC-HDBW5241R-S
- IPC-HDBW5241R1-AS-PV
- IPC-HDBW5242E-ZE-MF
- IPC-HDBW5242E-ZE-MF-ATC
- IPC-HDBW5242H-Z6E-MF
- IPC-HDBW5242H-ZE-MF
- IPC-HDBW5242H-ZHE-MF
- IPC-HDBW5242R-ASE-MF
- IPC-HDBW5441F-AS-E2
- IPC-HDBW5442E-Z4E
- IPC-HDBW5442E-Z4E-S3
- IPC-HDBW5442E-ZE
- IPC-HDBW5442E-ZE-OPAT
- IPC-HDBW5442E-ZE-S3
- IPC-HDBW5442E-ZHE
- IPC-HDBW5442E-ZHE-S3
- IPC-HDBW5442H-Z4E
- IPC-HDBW5442H-Z4HE-S3
- IPC-HDBW5442H-ZE
- IPC-HDBW5442H-ZH-SL
- IPC-HDBW5442H-ZHE
- IPC-HDBW5442H-ZHE-S3
- IPC-HDBW5442R-ASE
- IPC-HDBW5442R-ASE-OPAT
- IPC-HDBW5442R-ASE-S3
- IPC-HDBW5442R-S
- IPC-HDBW5449R-ASE-LED
- IPC-HDBW5449R-ASE-LED-S2
- IPC-HDBW5449R1-ZE-LED
- IPC-HDBW5541E-Z5E
- IPC-HDBW5541E-Z5E-S3
- IPC-HDBW5541E-ZE
- IPC-HDBW5541E-ZE-OPAT
- IPC-HDBW5541E-ZE-S3
- IPC-HDBW5541E-ZHE
- IPC-HDBW5541R-ASE
- IPC-HDBW5541R-ASE-OPAT
- IPC-HDBW5541R-ASE-S3
- IPC-HDBW5541R-S
- IPC-HDBW5541R1-AS-PV
- IPC-HDBW5831E-Z5E
- IPC-HDBW5831E-Z5HE
- IPC-HDBW5831E-ZE
- IPC-HDBW5831E-ZHE
- IPC-HDBW5831R-ZE
- IPC-HDBW5842E-Z4E-S2
- IPC-HDBW5842E-Z4E-S3
- IPC-HDBW5842E-ZE-S2
- IPC-HDBW5842E-ZE-S3
- IPC-HDBW5842E-ZHE-S3
- IPC-HDBW5842H-Z4HE-S2
- IPC-HDBW5842H-Z4HE-S2-ATC
- IPC-HDBW5842H-Z4HE-S3
- IPC-HDBW5842H-ZHE-S2
- IPC-HDBW5842H-ZHE-S2-ATC
- IPC-HDBW5842H-ZHE-S3
- IPC-HDBW5842R-ASE-S2
- IPC-HDBW5842R-ASE-S3
- IPC-HDBW71242E1-Z-X
- IPC-HDBW71242H-Z
- IPC-HDBW7442E1-Z-X
- IPC-HDBW7442E1-Z4-X
- IPC-HDBW7442H-Z-S2
- IPC-HDBW7442H-Z4-S2
- IPC-HDBW7842E1-Z-X
- IPC-HDBW7842E1-Z4-X
- IPC-HDBW7842H-Z-S2
- IPC-HDBW7842H-Z4-S2
- IPC-HDBW8841H-Z-LB
- IPC-HDBW8841H-Z4-LB
- IPC-HDEW8441R-Z
- IPC-HDEW8841R-Z
- IPC-HDPW1230R1-S5
- IPC-HDPW1230R1-ZS-S5
- IPC-HDPW1431R1-ZS-S4
- IPC-HDPW5241G-ZE
- IPC-HDPW5242G-ZE-MF
- IPC-HDPW5442G-ZE
- IPC-HDPW5541G-ZE
- IPC-HDW1230C-A
- IPC-HDW1230DT-STW
- IPC-HDW1230DT1-S5
- IPC-HDW1230S-S5
- IPC-HDW1230T-ZS-S5
- IPC-HDW1230T1-S5
- IPC-HDW1230T1-ZS-S5
- IPC-HDW1239T1-A-LED-S5
- IPC-HDW1239T1-LED-S5
- IPC-HDW1430DT-STW
- IPC-HDW1430T1-S5
- IPC-HDW1431S-S4
- IPC-HDW1431T-ZS-S4
- IPC-HDW1431T1-A-S4
- IPC-HDW1431T1-S4
- IPC-HDW1431T1-ZS-S4
- IPC-HDW1439T1-LED-S4
- IPC-HDW1530T-S6
- IPC-HDW1830T-S6
- IPC-HDW2230T-AS-S2
- IPC-HDW2231T-AS-S2
- IPC-HDW2231T-ZS-S2
- IPC-HDW2231TM-AS-S2
- IPC-HDW2239T-AS-LED-S2
- IPC-HDW2241T-S
- IPC-HDW2241T-ZS
- IPC-HDW2241TM-S
- IPC-HDW2249T-S-IL
- IPC-HDW2249TM-S-IL
- IPC-HDW2431T-AS-S2
- IPC-HDW2431T-ZS-S2
- IPC-HDW2431TM-AS-S2
- IPC-HDW2439T-AS-LED-S2
- IPC-HDW2441T-S
- IPC-HDW2441T-ZS
- IPC-HDW2441TM-S
- IPC-HDW2449T-S-IL
- IPC-HDW2449TM-S-IL
- IPC-HDW2531T-AS-S2
- IPC-HDW2531T-ZS-S2
- IPC-HDW2531TM-AS-S2
- IPC-HDW2541T-S
- IPC-HDW2541T-ZS
- IPC-HDW2541TM-S
- IPC-HDW2549T-S-IL
- IPC-HDW2549TM-S-IL
- IPC-HDW2831T-AS-S2
- IPC-HDW2831T-ZS-S2
- IPC-HDW2831TM-AS-S2
- IPC-HDW2841T-S
- IPC-HDW2841T-ZS
- IPC-HDW2841TM-S
- IPC-HDW2849T-S-IL
- IPC-HDW2849TM-S-IL
- IPC-HDW3241EM-S-S2
- IPC-HDW3241T-ZAS
- IPC-HDW3241T-ZS-S2
- IPC-HDW3241TM-AS
- IPC-HDW3249H-AS-PV
- IPC-HDW3249TM-AS-LED
- IPC-HDW3249TM-AS-NI
- IPC-HDW3441EM-S-S2
- IPC-HDW3441T-ZAS
- IPC-HDW3441T-ZS-S2
- IPC-HDW3441TM-AS
- IPC-HDW3449H-AS-PV
- IPC-HDW3449H-AS-PV-S3
- IPC-HDW3449H-AS-PV-S4
- IPC-HDW3449H-ZAS-PV
- IPC-HDW3449TM-AS-LED
- IPC-HDW3449TM-AS-NI
- IPC-HDW3541EM-S-S2
- IPC-HDW3541T-ZAS
- IPC-HDW3541T-ZS-S2
- IPC-HDW3541TM-AS
- IPC-HDW3549H-AS-PV
- IPC-HDW3549H-AS-PV-S3
- IPC-HDW3549H-AS-PV-S4
- IPC-HDW3549H-ZAS-PV
- IPC-HDW3549TM-AS-LED
- ipc-hdw3841em-as
- IPC-HDW3841EM-S-S2
- IPC-HDW3841T-ZAS
- IPC-HDW3841T-ZS-S2
- IPC-HDW3841TM-AS
- IPC-HDW3849H-AS-PV
- IPC-HDW3849H-AS-PV-S3
- IPC-HDW3849H-AS-PV-S4
- IPC-HDW3849H-ZAS-PV
- IPC-HDW4231EM-AS-S4
- IPC-HDW4231T-Z-S4
- IPC-HDW4241EM-S
- IPC-HDW4431EM-AS-S4
- IPC-HDW4431T-Z-S4
- IPC-HDW4441EM-S-0280B
- IPC-HDW4441EM-S-0360B
- IPC-HDW4541EM-S
- IPC-HDW4541T-ZS
- IPC-HDW4831EM-ASE
- IPC-HDW5241H-AS-PV
- IPC-HDW5241H-ASE-PV
- IPC-HDW5241T-ZE
- IPC-HDW5241T-ZE-S3
- IPC-HDW5241TM-AS-LED
- IPC-HDW5241TM-ASE
- IPC-HDW5241TM-ASE-S3
- IPC-HDW5242T-ZE-MF
- IPC-HDW5442T-ZE
- IPC-HDW5442T-ZE-S3
- IPC-HDW5442TM-AS-LED
- IPC-HDW5442TM-ASE
- IPC-HDW5442TM-ASE-S3
- IPC-HDW5449H-ASE-D2
- IPC-HDW5449H-ZE-LED
- IPC-HDW5449H-ZE-LED-S2
- IPC-HDW5449TM-SE-LED
- IPC-HDW5541H-AS-PV
- IPC-HDW5541H-ASE-PV
- IPC-HDW5541T-ZE
- IPC-HDW5541T-ZE-S3
- IPC-HDW5541TM-ASE
- IPC-HDW5541TM-ASE-S3
- IPC-HDW5831R-ZE
- IPC-HDW5842T-ZE-S2
- IPC-HDW5842T-ZE-S3
- IPC-HDW5842TM-ASE-S3
- IPC-HDW5842TM-SE-S2
- IPC-HDW5849H-ASE-LED
- IPC-HDW8341X-BV-3D
- IPC-HDW8441X-3D
- IPC-HDW8441X-BV-3D
- IPC-HF5241E-E
- IPC-HF5241F-ZE
- IPC-HF5242E-E-MF
- IPC-HF5442E-E
- IPC-HF5442F-ZE-S3
- IPC-HF5541E-E
- IPC-HF5541F-ZE-S3
- IPC-HF5842F-ZE-S2
- IPC-HF5842F-ZE-S3
- IPC-HF71242F
- IPC-HF71242F-Z-X
- IPC-HF7442F-Z-S2
- IPC-HF7442F-Z-X
- IPC-HF7842F-Z-S2
- IPC-HF7842F-Z-X
- IPC-HFS7842-Z-5G-LED
- IPC-HFS8449G-Z7-LED
- IPC-HFS8849G-Z3-LED
- IPC-HFW1230DS-SAW
- IPC-HFW1230DS1-S5
- IPC-HFW1230DT-STW
- IPC-HFW1230S-S5
- IPC-HFW1230S1-S5
- IPC-HFW1230T-ZS-S5
- IPC-HFW1230T1-ZS-S5
- IPC-HFW1239S1-A-LED-S5
- IPC-HFW1239S1-LED-S5
- IPC-HFW1430DS-SAW
- IPC-HFW1430DT-STW
- IPC-HFW1431S-S4
- IPC-HFW1431S1
- IPC-HFW1431S1-A-S4
- IPC-HFW1431S1-S4
- IPC-HFW1431T-ZS-S4
- IPC-HFW1431T1-ZS-S4
- IPC-HFW1439S1-LED-S4
- IPC-HFW1530S-S6
- IPC-HFW1830S-S6
- IPC-HFW2230S-S-S2
- IPC-HFW2231M-AS-I2-B-S2
- IPC-HFW2231S-S-S2
- IPC-HFW2231T-AS-S2-0360B
- IPC-HFW2231T-AS-S2-0800B
- IPC-HFW2231T-ZAS-S2
- IPC-HFW2231T-ZS-S2
- IPC-HFW2239M-AS-LED-B-S2
- IPC-HFW2239S-SA-LED-S2
- IPC-HFW2241S-S
- IPC-HFW2241T-AS-0360B
- IPC-HFW2241T-AS-0800B
- IPC-HFW2241T-ZAS
- IPC-HFW2241T-ZS
- IPC-HFW2249S-S-IL
- IPC-HFW2249T-AS-IL-0360B
- IPC-HFW2249T-AS-IL-0800B
- IPC-HFW2431DG-4G-SP-EAU-B
- IPC-HFW2431DG-4G-SP-LA-B
- IPC-HFW2431S-S-S2
- IPC-HFW2431T-AS-S2-0360B
- IPC-HFW2431T-AS-S2-0800B
- IPC-HFW2431T-ZAS-S2
- IPC-HFW2431T-ZS-S2
- IPC-HFW2439M-AS-LED-B-S2
- IPC-HFW2439S-SA-LED-S2
- IPC-HFW2441S-S
- IPC-HFW2441T-AS
- IPC-HFW2441T-AS-0800B
- IPC-HFW2441T-ZAS
- IPC-HFW2441T-ZS
- IPC-HFW2449S-S-IL
- IPC-HFW2449T-AS-IL-0360B
- IPC-HFW2449T-AS-IL-0800B
- IPC-HFW2531S-S-S2
- IPC-HFW2531T-AS-S2-0360B
- IPC-HFW2531T-AS-S2-0800B
- IPC-HFW2531T-ZAS-S2
- IPC-HFW2531T-ZS-S2
- IPC-HFW2541E-S
- IPC-HFW2541S-S-S2
- IPC-HFW2541T-AS
- IPC-HFW2541T-ZAS
- IPC-HFW2541T-ZS
- IPC-HFW2549S-S-IL
- IPC-HFW2549T-AS-IL-0360B
- IPC-HFW2549T-AS-IL-0800B
- IPC-HFW2831S-S-S2
- IPC-HFW2831T-AS-S2
- IPC-HFW2831T-ZAS-S2
- IPC-HFW2831T-ZS-S2
- IPC-HFW2841S-S
- IPC-HFW2841T-AS
- IPC-HFW2841T-ZAS
- IPC-HFW2841T-ZS
- IPC-HFW2849S-S-IL
- IPC-HFW2849T-AS-IL-0360B
- IPC-HFW2849T-AS-IL-0600B
- IPC-HFW3241DF-AS-4G
- IPC-HFW3241E-AS
- IPC-HFW3241E-AS-S2
- IPC-HFW3241E-S-S2
- IPC-HFW3241E-SA
- IPC-HFW3241M-AS-I2-0360-B
- IPC-HFW3241M-AS-I2-0360B
- IPC-HFW3241M-AS-I2-0800B
- IPC-HFW3241M-AS-I2-1200B
- IPC-HFW3241T-ZAS
- IPC-HFW3241T-ZAS-S2
- IPC-HFW3241T-ZS
- IPC-HFW3241T-ZS-S2
- IPC-HFW3249E-AS-LED
- IPC-HFW3249E-AS-NI
- IPC-HFW3249T1-AS-PV
- IPC-HFW3441DG-AS-4G-EAU-B
- IPC-HFW3441E-AS
- IPC-HFW3441E-AS-S2
- IPC-HFW3441E-S-S2
- IPC-HFW3441E-SA
- IPC-HFW3441M-AS-AG-I2
- IPC-HFW3441M-AS-I2-0360-B
- IPC-HFW3441M-AS-I2-0360B
- IPC-HFW3441M-AS-I2-0800B
- IPC-HFW3441M-AS-I2-1200B
- IPC-HFW3441M-AS-SFC-I2-0360B
- IPC-HFW3441M-AS-SFC-I2-0800B
- IPC-HFW3441T-AS-P
- IPC-HFW3441T-ZAS
- IPC-HFW3441T-ZAS-S2
- IPC-HFW3441T-ZS
- IPC-HFW3441T-ZS-S2
- IPC-HFW3449E-AS-LED
- IPC-HFW3449E-AS-NI
- IPC-HFW3449T1-AS-PV
- IPC-HFW3449T1-AS-PV-S3
- IPC-HFW3449T1-AS-PV-S4
- IPC-HFW3449T1-ZAS-PV
- IPC-HFW3541E-AS
- IPC-HFW3541E-AS-S2
- IPC-HFW3541E-S-S2
- IPC-HFW3541E-SA
- IPC-HFW3541T-ZAS
- IPC-HFW3541T-ZAS-S2
- IPC-HFW3541T-ZS
- IPC-HFW3541T-ZS-S2
- IPC-HFW3549E-AS-LED
- IPC-HFW3549T1-AS-PV
- IPC-HFW3549T1-AS-PV-S3
- IPC-HFW3549T1-AS-PV-S4
- IPC-HFW3549T1-ZAS-PV
- IPC-HFW3841E-AS
- IPC-HFW3841E-AS-S2
- IPC-HFW3841E-S-S2
- IPC-HFW3841E-SA
- IPC-HFW3841T-ZAS
- IPC-HFW3841T-ZAS-S2
- IPC-HFW3841T-ZS
- IPC-HFW3841T-ZS-S2
- IPC-HFW3849T1-AS-PV
- IPC-HFW3849T1-AS-PV-S3
- IPC-HFW3849T1-AS-PV-S4
- IPC-HFW3849T1-ZAS-PV
- IPC-HFW4231E-S-S4
- IPC-HFW4231E-Z-S4
- IPC-HFW4241T-AS
- IPC-HFW4241T-ZAS
- IPC-HFW4431E-S-S4
- IPC-HFW4431E-Z-S4
- IPC-HFW4441E-AS
- IPC-HFW4441T-AS
- IPC-HFW4441T-ZAS
- IPC-HFW4541E-AS
- IPC-HFW4541T-AS
- IPC-HFW4541T-ZAS
- IPC-HFW4831E-SE
- IPC-HFW4831T-ASE
- IPC-HFW4841T-AS
- IPC-HFW4841T-ZAS
- IPC-HFW5241E-ASE-S3
- IPC-HFW5241E-SE
- IPC-HFW5241E-Z12E
- IPC-HFW5241E-Z12E-S3
- IPC-HFW5241E-Z5E
- IPC-HFW5241E-Z5E-S3
- IPC-HFW5241E-ZE
- IPC-HFW5241E-ZE-S3
- IPC-HFW5241E-ZHE
- IPC-HFW5241T-AS-PV
- IPC-HFW5241T-ASE-0280B
- IPC-HFW5241T-ASE-0280B-S3
- IPC-HFW5241T-ASE-0800B
- IPC-HFW5241T-ASE-0800B-S3
- IPC-HFW5241T-ASE-NI
- IPC-HFW5241T-SE-0280B
- IPC-HFW5241T-SE-0280B-S3
- IPC-HFW5241T-SE-0800B
- IPC-HFW5241T-SE-0800B-S3
- IPC-HFW5242E-ZE-MF
- IPC-HFW5242E-ZE-MF-ATC
- IPC-HFW5242H-Z6E-MF
- IPC-HFW5242H-ZE-MF
- IPC-HFW5242H-ZHE-MF
- IPC-HFW5242T-ASE-MF
- IPC-HFW5442E-ASE-S3
- IPC-HFW5442E-SE
- IPC-HFW5442E-Z4E
- IPC-HFW5442E-Z4E-S3
- IPC-HFW5442E-ZE
- IPC-HFW5442E-ZE-OPAT
- IPC-HFW5442E-ZE-S3
- IPC-HFW5442E-ZHE
- IPC-HFW5442E-ZHE-S3
- IPC-HFW5442H-Z4E
- IPC-HFW5442H-Z4E-S3
- IPC-HFW5442H-Z4HE-S3
- IPC-HFW5442H-ZE
- IPC-HFW5442H-ZH-SL
- IPC-HFW5442H-ZHE
- IPC-HFW5442H-ZHE-S3
- IPC-HFW5442T-ASE
- IPC-HFW5442T-ASE-OPAT
- IPC-HFW5442T-ASE-S3
- IPC-HFW5442T-SE
- IPC-HFW5442T-SE-S3
- IPC-HFW5449E-SE-LED
- IPC-HFW5449E-SE-LED-S2
- IPC-HFW5449T-ASE-LED
- IPC-HFW5449T-ASE-LED-S2
- IPC-HFW5449T1-ASE-D2
- IPC-HFW5449T1-ZE-LED
- IPC-HFW5449T1-ZE-LED-S2
- IPC-HFW5541E-ASE-0280B-S3
- IPC-HFW5541E-SE
- IPC-HFW5541E-Z5E
- IPC-HFW5541E-Z5E-S3
- IPC-HFW5541E-ZE
- IPC-HFW5541E-ZE-OPAT
- IPC-HFW5541E-ZE-S3
- IPC-HFW5541E-ZHE-S3
- IPC-HFW5541T-AS-PV-0280B
- IPC-HFW5541T-AS-PV-0800B
- IPC-HFW5541T-ASE-0280B
- IPC-HFW5541T-ASE-0280B-S3
- IPC-HFW5541T-ASE-0800B
- IPC-HFW5541T-ASE-0800B-S3
- IPC-HFW5541T-ASE-OPAT
- IPC-HFW5541T-SE-0280B
- IPC-HFW5541T-SE-0280B-ATC
- IPC-HFW5541T-SE-0280B-S3
- IPC-HFW5541T-SE-0800B
- IPC-HFW5541T-SE-0800B-S3
- IPC-HFW5831E-Z5E
- IPC-HFW5831E-ZE
- IPC-HFW5831E-ZHE
- IPC-HFW5842DK1-Z-5G
- IPC-HFW5842DK1-Z4-5G
- IPC-HFW5842E-ASE-S3
- IPC-HFW5842E-Z4E-S2
- IPC-HFW5842E-Z4E-S3
- IPC-HFW5842E-ZE-S2
- IPC-HFW5842E-ZE-S3
- IPC-HFW5842E-ZHE-S3
- IPC-HFW5842H-Z4HE-S2
- IPC-HFW5842H-Z4HE-S2-ATC
- IPC-HFW5842H-Z4HE-S3
- IPC-HFW5842H-ZHE
- IPC-HFW5842H-ZHE-S2
- IPC-HFW5842H-ZHE-S2-ATC
- IPC-HFW5842H-ZHE-S3
- IPC-HFW5842T-ASE-S2
- IPC-HFW5842T-ASE-S3
- IPC-HFW5842T-SE-S3
- IPC-HFW5849T1-ASE-LED
- IPC-HFW5849T1-ASE-LED-S2
- IPC-HFW71242H-Z
- IPC-HFW71242H-Z-X
- IPC-HFW7442H-Z-S2
- IPC-HFW7442H-Z-X
- IPC-HFW7442H-Z4-S2
- IPC-HFW7442H-Z4-X
- IPC-HFW7442H-ZFR
- IPC-HFW7842H-Z-S2
- IPC-HFW7842H-Z-X
- IPC-HFW7842H-Z4-S2
- IPC-HFW7842H-Z4-X
- IPC-HMW3230-M
- IPC-HMW3230-M12
- IPC-HUM4231S-L4
- IPC-HUM4231S-L5
- IPC-HUM4431S-L4
- IPC-HUM4431S-L5
- IPC-HUM8101
- IPC-HUM8241-E1
- IPC-HUM8241-E1-L1
- IPC-HUM8241-E1-L3-S2
- IPC-HUM8241-E1-L4
- IPC-HUM8241-E1-L5
- IPC-HUM8241-E2
- IPC-HUM8241-L1
- IPC-HUM8241-L3
- IPC-HUM8241-L4
- IPC-HUM8241-L5
- IPC-HUM8241E-E1-L3-S2
- IPC-HUM8241E-L3-S2
- IPC-HUM8441-E1
- IPC-HUM8441-E1-L1
- IPC-HUM8441-E1-L3-S2
- IPC-HUM8441-E1-L4
- IPC-HUM8441-E1-L5
- IPC-HUM8441-E2
- IPC-HUM8441-L1
- IPC-HUM8441-L4
- IPC-HUM8441-L5
- IPC-HUM8441E-E1-L3-S2
- IPC-HUM8441E-L3-S2
- IPC-HUM8531M-V-LED
- IPC-K22
- IPC-K22A
- IPC-K42
- IPC-K42A
- IPC-L26
- IPC-MBW4231-AS
- IPC-MBW4231-M12
- IPC-MBW4431-AS
- IPC-MBW4431-M12
- IPC-MDW4330-M12
- IPC-MFW7442K1-Z4-T40
- IPC-MFW7442K1-Z7-T40
- IPC-MFW7449Y-Z7-T44
- IPC-MFW7449Y-Z7-T8A
- IPC-MFW7842K1-Z4-T20
- IPC-MFW7842K1-Z7-T20
- IPC-MFW7849Y-Z4-T44
- IPC-MFW7849Y-Z4-T8A
- IPC-MW1230D-HM12
- IPC-MW1230D-VM12
- IPC-PDBW5831-B360
- IPC-PDBW82041-B360
- IPC-PDBW82041-B360-E4-ATC
- IPC-PDBW82041-B360-S2
- IPC-PDBW8840-A180
- IPC-PDW3849-A180-AS-PV
- IPC-PDW5849-A180-E2-ASTE
- IPC-PFW3849S-A180-AS-PV
- IPC-PFW5849-A180-E2
- IPC-PFW5849-A180-E2-ASTE
- IPC-PFW81642-A180
- IPC-PFW83242-A180
- IPC-PFW83242-A180-S2
- IPC-PFW8840-A180
- IPC-S21F
- IPC-S21FE
- IPC-S22F
- IPC-S41F
- IPC-S41FE
- IPC-S42F
- IPC-S42F-D
- IPC-T22A
- IPC-T22E
- IPC-T22EAP-0280B-imou
- IPC-T26E
- IPC-T42E
- IPC-TA22C
- IPC-TA22C-B
- IPC-TA42
- IPC-TA42-B
- IPC-TA42-D
- IPC-WL46A
- PSDW81642M-A180-D440-S3
- PSDW81642M-A360-D440-S3
- PSDW81642S-A360-D425
- PSDW82442M-A270-D440-S3
- PSDW83242M-A360-D845L-S3
- PSDW8842S-A180-D425
Leave a comment
